Caratteristiche di gestione
Tipo interruttore
What switch device has Non gestito
Connettività
Quantità di porte RJ-45
The number of basic switching RJ-45 Ethernet ports (sockets). 8
Tipo di porte RJ-45
The type/category of basic switching RJ-45 Ethernet ports (sockets). Gigabit Ethernet (10/100/1000)
Connettore di alimentazione Jack DC-ingresso
Collegamento in rete
Standard di rete
The way in which the network is working IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Supporto 10G
The product can use Oracle 10G No
Supporto controllo flusso Sì
Auto MDI/MDI-X
A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover Sì
Trasmissione dati
Capacità di commutazione
The data transfer capacity of the switch per second. 16 Gbit/s
Store-and-forward Sì
Supporto Jumbo Frames Sì
Frame Jumbo 9000
Design
Colore del prodotto
The colour e.g. red Grigio
Indicatori LED PoE, Potenza
Gestione energetica
Fonte di alimentazione inclusa
There is a power supply with this product. Sì
Voltaggio input DC 55 V
Corrente d'ingresso 1.3 A
Consumo energetico (max)
The maximum amount of power used by the device. 72 W
Power over Ethernet (PoE)
Supporto Power over Ethernet (PoE)
The device supports Power over Ethernet (PoE) Sì
Quantità porte Power over Ethernet (PoE) 8
Condizioni ambientali
Intervallo temperatura di funzionamento
The minimum and maximum temperatures at which the product can be safely operated. 0 - 40 °C
Intervallo di temperatura
The minimum and maximum temperatures at which the product can be safely stored. -40 - 70 °C
Range di umidità di funzionamento 10 - 90%
Umidità 10 - 90%
Dimensioni e peso
Larghezza
The measurement or extent of something from side to side. 240 mm
Profondità
The distance from the front to the back of something. 105 mm
Altezza
Altezza del prodotto 26 mm
Peso
Il peso del prodotto senza imballaggio (peso netto). Se possibile, il peso netto viene espresso compreso di accessori standard e forniture . Notate che alle volte il produttore interpreta troppo seriamente il peso del prodotto,tralasciando il peso degli accessori e/o fornimenti . 610 g
Dati su imballaggio
Cavi inclusi AC
Guida rapida
Instructions Sì
Adattatore AC/DC Sì
Larghezza imballo
The distance from one side of the packaging to the other. 256 mm
Profondità imballo
The distance from the front to the back of the packaging. 132 mm
Altezza imballo
The distance from the top to the bottom of the packaging. 78 mm
Peso dell'imballo
Weight of the packaged product. 1,26 kg
Dati logistici
Larghezza scatola principale 283 mm
Lunghezza del cartone principale 415 mm
Altezza scatola principale 282 mm
Codice del Sistema Armonizzato (SA) 85176990
Peso del cartone principale 9 kg
