- ErP 2014 Lot 3Yes
- Operating Temperature0-40°C
- PFCActive PFC
- ATX 24 Pin Connectors1
- EPS 4+4 Pin Connectorsx1 = 1x (700mm)1
- Power Good Signal100 - 150 ms
- EPS 8 Pin Connectorx1 = 1x (700mm)
- 80 PLUS Rating80 PLUS Gold
- Warranty5 Years
- Fan Size120mm
- Category500 to 750W
- MTBF>100,000 hours @ 25℃ ambient
- Input Frequency47-63Hz
- 80 Plus EfficiencyGold
- ModularNon Modular
- Fan BearingHDB
- Input Voltage100-240V
- PCI-e 6+2 Pin Connectors2
- SATA Connectors6
- Peripheral 4 Pin Connectors3
- ProtectionsOVP
- ATX VersionATX 12V V2.52
- ProtectionsOPP
- ProtectionsSCP
- Dimensions (L x W x H)140 x 150 x 86 mm
- ProtectionsUVP
- ProtectionsOTP
- ProtectionsOCP
- SeriesG Series
- RegulatoryCCC
- Input Current750W / 850W: 10 – 6 A | 1000W: 15 – 8 A
- RegulatoryCE
- RegulatoryEAC
- Efficiency≥90% @ Typical Load
- RegulatorycTUVus
- RegulatoryFCC
- Hold Up Time≥15ms at 100% load
- RegulatoryBSMI
- RegulatoryCB
- RegulatoryTUV
- RegulatoryRoHS2.0
- RegulatoryKC+KCC
- RegulatoryBIS
- ModelMPW-5001-ACAAG
