Model Number
Black: E681-KHNN-S00, White: E681-WHNN-S00
Color(s)
Black / White
Materials - Front Panel
Tempered Glass
Material - Side Panel (Left)
Tempered Glass
Material - Side Panel (Right)
Steel
Dimensions (L x W x H)
425 x 285 x 400 mm (Incl. Protrusions), 420 x 285 x 380 mm (Excl. Protrusions)
Volume
48.45 L (Liters Incl. Protrusions)
Motherboard Support
ITX / Micro-ATX / ATX
Expansion Slots
7
5.25" Drive Bays
0
3.5" Drive Bays
1 (Max. 2)
2.5" Drive Bays
2 (Max. 3)
I/O Panel - USB Ports
1 x USB Type C 20Gbps, 2 x USB 3.0
I/O Panel - Audio In / Out
1x 3.5mm Combo
Pre-installed Fans - Rear
1x 120mm ARGB PWM
Pre-installed Fans - Side Mount
3x 120mm ARGB PWM reverse fan
Fan Support - Top
2x 140mm / 3x 120mm
Fan Support - Rear
1x 120mm
Fan Support - Side Mount
2x 140mm / 3x 120mm
Fan Support - Bottom
3x 120mm
Radiator Support - Top
120 / 240 / 280 / 360mm
Radiator Support - Bottom
120 / 240 / 360mm
Radiator Support - Side Mount
120 / 240 / 280mm
Clearance - CPU Cooler
160mm
Clearance - PSU
240mm
Clearance - Graphics Card
410mm
Power Supply Support
ATX
Warranty
2 years
Size
Mid Tower
Series
Elite Series
