Camera Vs 2Mp Bullet 3,6Mm Bnc Ir30M Ip67 12Vdc 3.2W

Dahua S6 Version | Telecamera HD CVI da sorveglianza da esterno Dahua HAC-HFW1200T evoluzione della HAC-HFW1220RM, bullet con 4 tecnologie in 1: HDCVI / HDTVI / AHD / TVI, 1080P FULL-HD 2MP, ottica 3.6mm e sensore d'immagine 2MP CMOS. Illuminatore Smart IR 1 LED 30M, Protezione IP67, Day/Night (ICR), Metallo





• 4 Tecnologie in 1: HDCVI / HDTVI / AHD / TVI- Risoluzione 1080P 2MP FULL HD
• Illuminatore IR 1 LED 30M - Day/Night(ICR), BLC / HLC / DWDR
• Protezione IP67(Polveri/immersione) - Alimentatore 12V DC (non incluso) - Garanzia 24 mesi
• Telecamera da esterno HD CVI 4in1 - Dahua
• Serie S6
• 4 Tecnologie in 1: HDCVI / HDTVI / AHD / TVI
• Tecnologie switchabili tramite OSD Menù o UTC Controller (non incluso)
• Risoluzione: 2Megapixel 2 MP FULL HD 1080P
• Ottica Fissa 3.6mm
• Sensore d'immagine 2MP CMOS
• Day/Night(ICR), BLC, HLC, AGC, DWDR
• Illuminatore Smart IR 1 LED (30 M)
• OSD Menù multilingua
• Uscita Video: 1 Canale BNC uscita video alta definizione / CVBS (intercambiabili)
• Alimentatore 12V DC (non incluso)
• Protezione IP67 (Polveri / Immersione) - Adatta ad ambienti interni / esterni
• Materiale: Metallo
• Dimensione: 174.5 mm × 70.6 mm × 72.3 mm (6.87" × 2.78" × 2.85")
• Garanzia 24 mesi





Model HAC-HFW1200T-S6



Camera

Image Sensor 2 MP CMOS

Effective Pixel 1920(H)×1080(V), 2MP

Scanning System Progressive

Electronic Shutter Speed

PAL: 1/25~1/100000s

NTSC: 1/30~1/100000s

Min. Illumination 0.01 lux@F2.0 (Color, 30 IRE)

0.001 lux@F2.0 (B/W, 30 IRE)

0 lux (Illuminator on)

S/N Ratio >65dB

IR Distance Up to 30m (98feet)

IR On/Off control Auto / Manual

IR LEDs 1

Angle Adjustment Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°

Lens Type Fixed-focal

Mount Type M12

Focal Length 3.6mm

Max Aperture F2.0

Field of View H: 102°; V: 60°; D: 129°

Iris Control Fixed

Close focus distance 0.7 m (2.30 ft)

PAN/Tilt Range

Detect Observe Recognize Identify

50.9 m (166.99 ft) 20.3 m (66.60 ft) 10.2 m (33.46 ft) 5.1 m (16.73 ft)





Video



Resolution

1080p (1920 × 1080); 960H (960 × 576/960 × 480)





Video Frame Rate



CVI:

PAL: 1080p@25 fps;

NTSC: 1080p@30 fps;



AHD:

PAL: 1080p@25 fps;

NTSC: 1080p@30 fps;



TVI:

PAL: 1080p@25 fps;

NTSC: 1080p@30 fps;



CVBS:

PAL: 960H;

NTSC: 960H

Day/Night Auto (ICR) //Color/B/W

BLC Mode BLC / HLC / DWDR



WDR DWDR

Gain control Auto

Noise reduction 3D NR

White Balance Auto / Manual

Illumination Mode Smart IR

Mirror Yes

Privacy Masking Off/On (8 areas, rectangle)



Certifications

CE-LVD: EN 62368-1;

CE-EMC: EN 55032; EN 55035;

FCC: 47 CFR FCC Part 15, Subpart B;

UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14





Port



Video output

choices of CVI/TVI/AHD/CVBS by one BNC port





Power



Power Supply 12V DC ±30%

Power Consumption Max 3.2 W (12 VDC, IR on)





Environmental



Operating Consumption

-40°C ~ +60°C (-40°F ~ +140°F) /<95% (RH), non-condensing



Storage condition

-40°C ~ +60°C (-40°F ~ +140°F) /<95% (RH), non-condensing



Ingress Protection &Vandal Resistance

IP67



Construction

Casing Metal



Dimensions

174.5 mm × 70.6 mm × 72.3 mm (6.87" × 2.78" × 2.85")



Net Weight

0.34 kg (0.75 lb)



Gross Weight

0.46kg (1.01lb)



Installation

Wall mount; ceiling mount; vertical pole mount
