| Model NO. | QH-D5004E |
| OPERATION SYSTEM | LINUX |
| VIDEO | |
| VIDEO SYSTEM | NTSC/PAL Switch Selectable |
| INPUT | BNC*4,1.0Vp-p,75ohm |
| CVBS OUTPUT | NTSC:720*480 |
| PAL:720*576 | |
| SPOT | NA |
| HDMI OUTPUT | 1 HDMI Output |
| VGA OUTPUT | 1 VGA Output |
| LOOP OUT | NA |
| AUDIO | |
| INPUT | 1CH, RCA |
| OUTPUT | 1CH, RCA |
| TALK BACK | YES |
| CONTROL | |
| MOUSE | 2*USB2.0 |
| IR CONTROLLER | YES |
| KEYBOARD | NA |
| STORAGE | |
| BUILD IN INTERFACE | SATA 2.6 *1(1*HDD 2TB ) |
| DISPLAY | |
| DIVISION | 1, 4 |
| ZOOM | Preview&Playback Zoom Support |
| RECORDING | |
| COMPRESSION | H.264(High profile) |
| RECORDING MODE | Manual/Schedule/Motion Detection/Sensor（Optional） |
| RESOLUTION | Mode 1: 4CH 720P |
| Mode 2: 2CH 720P + 2CH 960H | |
| Mode 3: 4CH 960H | |
| RECORD FRAME RATE | PAL: 4CH 720P@25fps, NTSC: 4CH 720P@30fps |
| QUALITY | Worst, Worse, Bad, Normal, Better, Best |
| PLAYBACK | |
| SYNC PLAYBACK | 1 , 4 |
| SPEED | Normal, FF(1X, 2X, 4X, 8X,), Slow (1/2X, 1/4X, 1/8X) |
| SEARCH METHOD | Time, Event, Channels and Calendar |
| COMMUNICATION | |
| REMOTE ACCESS | IE ( 10.0 and below), ISS ( Windows XP/WIN7/WIN8 ), ISS MOBILE2 ( IOS, Android ) |
| REMOTE OPERATION | Remote view, remote playback, remote setup |
| NETWORK SERVICE | TCP/IP、PPPOE 、DDNS、FTP、NTP UPNP |
| MOBILE DEVICE | Iphone, Ipad, Android |
| 3G EXTERNAL MODULE | Yes, with USB 2.0 Port |
| WAN RJ45 | 10/100Mbit/s |
| WIFI EXTERNAL MODULE | Yes, with USB 2.0 Port, 100Meters |
| GUI INTERFACE | Supported GUI 16 Bit True Color |
| PTZ PROTOCOL | PELCO-D, PELCO-P, etc 17 kinds of protocol |
| BACKUP | |
| INTERNAL | NA |
| EXTERNAL | 2*USB2.0 |
| NETWORK | YES |
| FILE FORMAT | AVI/dav |
| GENERAL | |
| ALARM IN/OUT | NA |
| RS-485 | 1 |
| RS-232 | NA |
| UNIT DIMENSION(mm) | 260(L) x 44(H) x 221(W) |
| OPERATION TEMPERATURE | 10°～40° |
| WORKING HUMIDITY | 10% ~ 90% |
| POWER CONSUMPTION | DC 12V,2A, <6W (Exclude HDD) |
