Technical Specification
Model
DH-PFM351R-2700-EN
DH-PFM351R-2700-BS
DH-PFM351R-2700-US
Plug Type
European
British
American
Input
Rated Voltage
220Vac~240Vac
Voltage Range
180~300VAC @100%load
120~300VAC@50%load
Rated Frequency Range
57~63HZ
Power Factor
0.9
Output
Voltage
200/208/220/230/240 VAC
AC Voltage Regulation (Batt. Mode)
±1%
Frequency Range (Batt. Mode)
50Hz or 60Hz±0.5%
Transfer Time
0 ms
Waveform (Batt. Mode)
Pure Sinewave
Capacity
3000VA/2700W
Battery
Battery Type & Number
12 V/9 Ah x 6
Typical Recharge Time
4 hours recover to 90% capacity
Max.Recharge Current
1 A
Recharge Voltage
82.1VDC ± 1%
Indicators
LCD
Load level, battery level, AC mode, battery mode, bypass mode, and fault indicators
Alarm
Battery Mode
Sounding every 10 seconds
Low Battery
Sounding every second
Overload
Sounding every 0.5 second
Fault
Continuously sounding
Protection
Full Protection
Over temperature ,overload, discharge, and overcharge protection
Environmental
Operating Temperature
0℃~ +40℃(+32℉~ +104℉)
Operating Humidity
0~95% RH (non-condensing)
Altitude Range
<1000m (3280.84ft)
Construction
Color
Black
Noise Level
<50dB
Dimensions
630mmx438mmx88mm(24.8"x17.24"x3.46")
Weight
29.3kg (64.6lb)
