| Chipset | AMD X370 | |||||||||||||||||||||||||||||||||||
| CPU SUPPORT | AMD A-series APU / Ryzen CPU / NPU for Socket AM4 Maximum CPU TDP (Thermal Design Power) : 95Watt |
|||||||||||||||||||||||||||||||||||
| MEMORY | Support Dual Channel DDR4 3200(OC)/ 2933(OC)/ 2667/ 2400/ 2133/ 1866 MHz Support Non-ECC & ECC Un-buffered DIMM Memory modules 4 x DDR4 DIMM Memory Slot Max. Supports up to 64GB Memory * DDR4 2667 for AMD Ryzen CPU Ryzen - DDR Maximum Frequency Support Table(For better DDR4 compatibility, it is recommended to follow the table below to install DDR4 modules. Please refer to memory support list for more details.)
DR:Dual-rank DIMMs, 2R x4 or 2R x8 |
|||||||||||||||||||||||||||||||||||
| EXPANSION SLOT | 1 x PCI-E x16 3.0 Slot(x16 for Ryzen CPU only, NPU/APU run at x8 speed) 1 x PCI-E x16 2.0 Slot(x4)(share bandwidth w/ PCI-E x1 slot, when PCI-E x1 is occupied, PCI-E x16(x4) will run at x1 speed) 2 x PCI-E x1 2.0 Slot 2 x PCI Slot |
|||||||||||||||||||||||||||||||||||
| STORAGE | 6 x SATA3 Connector Support SATA RAID: 0,1,10 1 x M.2 Key M 32Gb/s Connector, support M.2 type 2242/ 2260/ 2280 SATA 6Gb/s & PCI-E Storage * M.2 (32Gb/s) : The bandwidth is depended on CPU, Ryzen is 32Gb/s ; APU & NPU is 16Gb/s. |
|||||||||||||||||||||||||||||||||||
| USB | 1 x USB 3.1 Gen2 Type-C Port 1 x USB 3.1 Gen2 Port 4 x USB 3.1 Gen1 Port 2 x USB 3.1 Gen1 Header 2 x USB 2.0 Header |
|||||||||||||||||||||||||||||||||||
| LAN | Realtek RTL8118AS - 10/100/1000 Controller Support Super LAN Surge Protection |
|||||||||||||||||||||||||||||||||||
| MULTI GRAPHICS | 2-way AMD Crossfire Technology | |||||||||||||||||||||||||||||||||||
| INTEGRATED VIDEO | By CPU model Supports DX12 Supports HDCP |
|||||||||||||||||||||||||||||||||||
| CODEC | Realtek ALC892 8-Channel Blu-ray Audio Support Biostar Hi-Fi |
|||||||||||||||||||||||||||||||||||
| REAR I/O | 1 x PS/2 1 x USB 3.1 Gen2 Type-C Port 1 x USB 3.1 Gen2 Port 4 x USB 3.1 Gen1 Port 1 x HDMI Connector, resolution up to 4096 x 2160 @24Hz or 3840 x 2160 @30Hz 1 x DVI-D Connector, resolution up to 1920 x 1200 @60Hz 1 x RJ-45 Port 6 x Audio Connector |
|||||||||||||||||||||||||||||||||||
| INTERNAL I/O | 2 x USB 3.1 Gen1 Header 2 x USB 2.0 Header 6 x SATA3 6Gb/s Connector 1 x M.2 Key M 32Gb/s Connector, support M.2 type 2242/ 2260/ 2280 SATA 6Gb/s & PCI-E Storage 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-Out Header 2 x CPU Fan Header 2 x System Fan Header 1 x Serial Header 2 x 5050 LED Header |
|||||||||||||||||||||||||||||||||||
| H/W MONITORING | CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU / System Fan Control System Voltage Monitoring |
|||||||||||||||||||||||||||||||||||
| DIMENSION | ATX Form Factor Dimension: 30.5cm x 24.4cm ( W x L ) | |||||||||||||||||||||||||||||||||||
| OS SUPPORT | Support Windows 7(x64) / 10(x64) | |||||||||||||||||||||||||||||||||||
| BUNDLE SOFTWARE | Racing GT Utility FLY.NET BullGuard |
|||||||||||||||||||||||||||||||||||
| ACCESSORIES | 4 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x User Manual |
|||||||||||||||||||||||||||||||||||
| FEATURES | VIVID LED DJ 5050 LED FUN ZONE Supports Double Hi-Fi GT TOUCH Dual BIOS Supports 100% Solid capacitor Supports BIOS-Flasher Supports BIOS Online Update |
